Model: LED three-door nitrogen oven
Model: XHMOQ-3D
Power source: 380V 3φ 50HZ 9.5KVA
Inner size: W700×D600×H1000mm
Outer size: W1200×D800×H1700mm
Temperature range: +10 ° C ~ 250 ° C Max
Degree control: automatic PID control, electronic sensing, digital display
Temperature system: CA induction rod, output with SSR contactless control
Temperature uniformity: at175 °C ± 1%
Heating time: +60 ° C ~ 250 ° C 40 min
Air inlet: Air φ 8mm, N2 φ6mm
Exhaust port: φ16mm WithAutomatic Damper
Box material: inner SUS304 stainless steel plate, external SS41# steel paint
Heating method: cover type electric heater
Safety device: leakage circuit breaker, over temperature protection device, electric overcurrent protection device, motor overheat current protection, machine abnormal buzzer display, three-phase reverse phase preventer, control button and anti-touch cover.
Standard accessories: flow meter, electromagnetic door buckle, test hole, round hole plate, data bag
Optional: programmable thermostat, recorder, six-point temperature display, automatic opening and closing exhaust door, three-color indicator light.
