First, the heating source has steam, electricity, far infrared, gas and electricity for users to choose
Second, the use temperature: steam heating 50-130 ° C, up to 140 ° C
Third, electricity, far infrared temperature 50-300 ° C, can be equipped with automatic control system or computer control system for users to choose
Fourth, the common steam pressure 0.2-0.8mpa (2-8kg/cm2)
Five, with electric heating according to type 1 calculation 15kw, practical 5-8kw / h
Six, special requirements indicate when ordering
Seven, non-standard oven price negotiable
Eight, the use temperature is greater than 140 ° C or less than 60 ° C, to be specified when ordering
Nine, the factory's factory drying car, baking plate size uniform, can be interchanged
Ten, baking tray size: 460X640X45mm
Application: It is suitable for heat curing, drying and dehydration of materials and products in pharmaceutical, chemical, food, agricultural and sideline products, aquatic products, light industry, heavy industry and other industries. Such as raw materials, raw drugs, Chinese herbal medicine pieces, extracts, powders, granules, granules, water pills, packaging bottles, pigment dyes, dehydrated vegetables, dried fruits, sausages, plastic resins, electrical components, baking varnish and so on.
Features:
Most of the hot air circulates in the tank, which is highly efficient and saves energy. The utility model utilizes the forced ventilation function, and the adjustable air distribution plate is arranged in the box, the material is evenly dried, and the heat source can be steam, hot water, electricity and far infrared, and the selection is wide. The whole machine has low noise and balanced operation. Temperature control, easy installation and maintenance. Wide range of applications, can dry a variety of materials, is a general drying equipment.
